Big Tex Tandem Axle Pipe Utility Trailer | 70PI-X
Product details
When it comes to hauling light-duty equipment on the farm or ranch, there’s nothing more versatile than the 70PI-X Tandem Axle Pipe Top Utility Trailer. Coming standard with an extra wide 83’’ wide deck, this trailer is built to transport small equipment and other loads for agricultural applications. It’s sturdy. It’s durable. It’s dependable. It’s everything you need in a cost-effective—yet adaptable—utility trailer that gets the job done from sunrise till sunset.
STANDARD FEATURE
AVAILABLE OPTIONS
Axles
2 – 3,500# Premium, Cambered Axles with Quick-Lubricating Hubs
Brakes
Electric Brake on Front Axle
Electric Brakes on 2nd Axle
Suspension
Multi-Leaf Spring w/ Equalizer
Coupler
2″ Demco EZ- Latch
2-5/16” Forged Coupler2-5/16” Stamped Coupler
Safety Chains
1/4″ Grd. 30 w/ Safety Latch Hook (2 ea)
Jack
2,000# Top Wind, Set-Back Jack with Removable Sand Foot
8,000# Drop-Leg Jack
2,000# Fold-Up Jack
Frame
4″ x 3″ x 1/4″ Angle
Cross-Members
3” x 2” x 3/16” Angle
Floor
Treated Pine Floor
Blackwood Pro Rubber Infused Lumber Floor (per linear foot)1/8” Diamond Plate Steel Floor (Per Square Foot)
Fenders
9″ x 72″ Rolled Formed w/ Back
Ramps
4′ Slide-In Angle Ramps
4′ Tall Bi-Fold Rear Ramp Gate w/ Coil Spring Assist
4′ Tall Rear Ramp Gate w/ Coil Spring Assist
5′ Stand Up Ramps
5′ Tall Rear Ramp Gate w/ Coil Spring Assist
4′ Heavy Duty Integrated Ramp Gate w/ Coil Spring
5′ Heavy Duty Integrated Ramp Gate w/ Coil Spring
Stake Pockets
Additional Stake Pockets (Each)
Trailer Plug
7-Way RV
Lights
L.E.D. D.O.T. Stop, Tail, Turn & Clearance
Wiring
Grommet-Mounted Lifetime L.E.D. Lighting
Tires
ST205/75 R-15 Load Range C
Bolt Pattern
5 Bolt
Spare Mount
Side Spare Tire Mount
Spare Tire
Spare Tire (ST205/75R-15 LR-C)
Spare Tire (ST225/75R-15 LR-D)
Paint Type
Professional Finish w/ Primer Standard
Paint Color
Black
Red
Grey
White
Desert Tan
Jet Blue
Slime Green
Implement Green
Equipment Orange
Medium Yellow
Sides
17″ Tall Open sides with 3″x 2” Angle uprights and 2″ x 2″ Square Tubing Top Rail
2′ High Sides (Open, Total Height with Top Rail)
3’ High Sides (Open, total height with Top Rail)
4’ High Sides (Open, total height with Top Rail)
Car Hauler Style (No Side Rails)
Enclose Sides w/ Expanded Metal (Per Square Foot)
Enclose Sides w/ Sheet Metal (Per Square Foot)
MODEL
70PI-14X
PULL TYPE
Bumperpull
GVWR
7000 lbs
GAWR (EA. AXLE)
3500 lbs
EMPTY WEIGHT
1780 lbs
CARGO CAPACITY
5220 lbs
BED LENGTH
14′
BED WIDTH
83″
A
169-1/2″
B
103″
C
72-1/2″
TONGUE LENGTH
44-1/2″
70PI-16X
1860 lbs
5140 lbs
16′
193-1/2″
115″
78-1/2″
70PI-18X
1940 lbs
5060 lbs
18′
217-1/2″
127″
90-1/2″
70PI-20X
2020 lbs
4980 lbs
20
240″
138″
102″
